Nice Blue-i Infrared Safety Beams
Product code6009228599390
Hard-wired infrared safety beam pair for gates and garage doors.
A matched transmitter and receiver pair that projects an invisible infrared beam across the gate or garage door opening. If a person, pet or vehicle breaks the beam while the door is closing, the operator stops and reverses. Blue-i beams are required to enable auto-close on Nice operators and work with most gate motors and alarm panels through a simple relay output.
- Residential
- Commercial
- Gate Automation
Key features
- Stops and reverses the door or gate when the beam is broken
- Enables timed auto-close on Nice operators
- Wide 12 – 24 V AC/DC supply range
- Selectable N/O or N/C relay output for third-party operators and alarm panels
Specifications
| Kit | Transmitter and receiver pair |
| Supply voltage | 12 – 24 V AC or DC |
| Range | Approx. 10 m |
| Infrared wavelength | 940 nm |
| Current draw | Receiver 15 mA · Transmitter 30 mA |
| Output | Relay, selectable N/O or N/C, 1 A @ 30 V max |
| Operating temperature | −20 °C to +70 °C |
| Lens | Sealed against dust and moisture |
Ideal applications
- Sliding and swing gates
- Roll-up garage doors
- Auto-close installations
Compatible with
- Nice DC Blue Absolute (required for auto-close)
- Nice and ET Nice sliding and swing gate operators with a beam input
- Most third-party gate operators and alarm panels via the relay output
Downloads
Loading published manuals…
Product information source: ET Nice — Gate automation range brochure
